Trawl units SI-10(2), SI-110(2), SI-110-F
|
|
|
Trawl units SI-10, SI-110 SI-110-2, SI-110-F used in the fish-finding systems and trawl probes manufactured by Simbia.
|
Technical data:
| Parameters, function | SI-10 | SI-10-2 | SI-110 | SI-110-2 | SI-110-F
| Operating maximum
depth, m
( special order ) |
1500
2500 |
1500
2500 |
1500
2500 |
1500
2500 |
1500
2500
| Maximum length of cableKG1-30 ( 6,3mm), m
KG1-55 ( 9,4mm), m |
500-4000
500-2700 |
500-4000
500-2700 |
500-4000
500-2700 |
500-4000
500-2700 |
500-4000
500-2700
| | Operating frequency, kHzchannel "Probe"channel "Catch" |
50±1
- |
50±1
- |
50±1
- |
50±1
- |
50±1
69,8 - 77,7
| | Depth of trawl movingaccuracy till 200 maccuracy above 200 m |
-
- |
-
- |
±3 m
±1,5 % |
±3 m
±1,5 % |
±3 m
±1,5 %
| | Temperature sensorrange, Ñaccuracy, Ñ |
-
- |
-
- |
- 5 to + 30
±0,3 |
- 5 to + 30
±0,3 |
- 5 to + 30
±0,3
| | Transducers | "Downward" | "Downward"
"Upward" | "Downward" | "Downward"
"Upward" | "Downward"
"Catch"
| | PowerU, VDCI, mA |
+ 37
20 to 50 |
+ 37
20 to 50 |
+ 37
50 to 80 |
+ 37
50 to 80 |
+ 37
50 to 80
| | Weight, kg | 7 | 8 | 7 | 8,5 | 8,5
| | Dimension, mm | 460õ300õ90 | 540õ300õ100 | 460õ300õ90 | 540õ300õ100 | 540õ300õ100
|
|
Scope of delivery:
Main:
- Trawl unit
- Operation documentation
Options:
- Installation kit
- Spare parts kit
|
| |
 |
|
| |
|
