Automatic identification system: Transas AIS T-101
|
|
|
Automatic identification system (AIS) Transas Ò-101.
Automatic exchange between vessels and shores of navigational,
static, route information; information about safety
at sea. Automatic receive of information GPS and
GLONAS.
Can be used for spreading and receive of diff. amendments
GLONAS through AIS channels. Possibility of maintenance
of telecommunication requests. Reserve way of AIS
synchronizing when GLONA/GPS - receiver fails.
|
Technical specifications:
| Parameters, function | Values
| | Frequency range | 156,025 - 162,025 MHz
| | Frequency step | 12,5, 25 kHz
| | Modulation and speed of transmitting | AIS-GMSK, 9600 bite/sec
DCS - FM/FSK, 1200 bite/sec
| | Sensitivity | -107 dBm
| | Capacity of radio transmitter radiation | 2 W, 12,5 W
| | Consumed capacity | 60 W (Main unit)
6 W (Control panel)
| | Working temperature | from -15 to +55°Ñ
| | Storage temperature | from -20 to +70°Ñ
| | Permissible vibrations | Corresponds to IEC 60945
| | Climatic execution | Proof, corresponds to IEC60945, IP21
| | GLONA/GPS-receiver: |
| | Amount of channels | 16
| | Frequency | L1, C/A
| | Frequency of coordinates defining | 45 m (in DGNSS - 1-10 m)
| | Dimensions of the main unit | 225 õ 205 õ 172 mm (without mounting)
230 õ 221 õ 185 mm (with mounting)
| | Height of VHF-antenna | 500 mm
| | Dimensions of antenna box | 140 õ 120 õ 80 mm
| | GNSS antenna dimensions (GLONAS) | truncated cone with diameter in a basis - 105 mm, height 180,5 mm
| | GNSS antenna dimensions (NAVSTAR) | dome with diameter in a basis 80 mm, height - 80 mm
| | Dimensions of control panel unit and indication | 230 õ 134 õ 60 mm (without mounting tools)
245 õ 134 õ 60 mm (with frame of mounting)
257 õ 134 õ 60 mm (with screws of control panel angle fixing)
| | Mass of the main unit | 8,0 kg
| | Mass of VHF-antenna | 0,4 kg
| | Mass of GNSS antenna (GLONAS) | 0,44 kg
| | Mass of GNSS antenna (NAVSTAR) | 0,12 kg
| | Mass of control panel unit and indication | 2,4 kg |
|
A scope of delivery:
- Antenna GNSS;
- VHF-antenna;
- Antenna cables VHF and GNSS;
- Main unit;
- Control and reflection panel AIS;
- A set of mounting tools for installation;
- Power suplly unit SI-V-180;
- Gyro IGL-01;
- RMRS certificate.
|
| |
 |
|
| |
|
