| Parameters, function | Values
|
| VHF section: |
|
| Class of emission | G3E (voice), G2B (DSC)
|
| Communication system | Simplex/Semi-duplex
|
| Programmed channels | Main version: 55 channels (RR Apendix 18)
American version: Main version, USA channels, weather forecast channels
Scandinavian version: Main version
Fishing/Private channels
|
| Power supply voltage | 24 V DC, +30%, -10%
|
| Display | 24 characters x 2 lines, character 5x7 dots, backlit LCD
|
| Transmitter: |
|
| Frequency range | 155.00 - 161.475 MHz
|
| Output power | 25 W, reducible to1 W
American version: Channels 67, 13 - automatic limit up to 1 W, manual override FULL
|
| Frequency stability | 1,5 kHz (from -20 to +55°C)
|
| Time-out timer | Deactivates the transmitter after an interrupted transmission of more than 5 minutes
|
| Receiver: |
|
| Frequency range | 155.00 - 166.075 MHz
|
| Receiving system | Double-conversion superheterodyne
IF21.4 MHz and 455 kHz
|
| AF Output power | 3 W (build-in loud speaker)
2 mW (handset)
|
| Audio Response De-emphasis | 6 dB/oct +1/-3 dB
|
| Sensitivity | 5 dBµV at SINAD 20 dB
|
| Adjacent Channel Selectivity | 70 dB (from +15°C to +35°C)
|
| DSC Section: |
|
| Distress call and Message | Distress call attempt is transmitted as five consecutive calls. It is repeated after a random delay of between 3.5 and 4.5 min from the beginning of initial call.
|
| Message storage (Receive) | 50 distress messages plus 50 non-distress messages
|
| Message storage (Transmit) | 50 non-distress plus 99 files containing station ID, telephone No.
|
| Interface | Navigational data: IEC61162
Printer: FURUNO MIF (with Interface box)
|
| Alarm | Sound and visual
|
| Receiver characteristics: |
|
| DSC frequency | CH 70
|
| Calling sensitivity | Symbol error rate 10-2, input -3 dBµV
|
| Watch keeping | continuous watch on CH 70 |
