| Parameters, function | Values
|
| Working range of coastal station | From 250 to 400 mile
|
| The frequency of receiving | 518 kHz
|
| The class of receiving signal | Frequency telegraphy F1B
|
| Input impedance | 50 Îm
|
| Modes of receiving | ???
|
| Receiver sensitivity | Not worse than 1 mkV
|
Receiver selectivity:
- At a level 6 dB
- At a level 60 dB |
300 Hz
2 kHz
|
| Stray radiation | Not more than 2 nVt
|
| Input receiver protection | 30 V (root-mean-square denotation)
|
| Memory capacity | 127.000 symbols (in average more than 300 messages)
|
| A type of receiving antenna | Active with coaxial cable and flagpole 60 centimeters antenna (120 centimeters - option)
|
| Output data | 7 bit ASCII
|
| Display: |
|
| Type of display | Monochrome LCD
|
| Size along a diagonal | 4,5 inches
|
| Resolution | 192 õ 128 pix
|
| Amount of lines | 16
|
| Amount of symbols in a line | 32
|
| Display modes (pages) | NAVTEX text
Navigational data (coordinates, date/time, speed)
|
| Power supply: |
|
| Voltage | From 11 to 40 VDC
|
| Consumption capacity | Not more than 5 Vt
|
| Conditions of operation: |
|
| Temperature | From -15 to +50°Ñ (receiver)
From -20 to +60°Ñ (antenna)
|
| Humidity | Till 93% (during 40°C)
|
| Receiver dimensions | 215 õ 80 õ 130 mm
|
| Mass | around 650 g |
