| Parameters, function | Values
|
Working modes:
- bearing mode
- receiver mode |
bearing till received signal
receiving of VHF radio signal
|
| Bearing indications | graphical and digital
|
| Accuracy | 1 degree (digital)
5 degrees (graphical)
|
| Sensitivity | 1 mV/m and less
|
| Correction of bearing | automatic, after making corrections
|
| Receiver range | 118 - 174 MHz
|
| Sensitivity | less than 5 mV/m
|
| Frequency type of received channel | SHIP (from vessel to shore, it means - for transmission)
COAST (from shore to vessel, it means - for receiving)
F (weather channels)
USER (user channels)
ÀÌ (channel for SOS signal)
|
| Channel type of connection | INTERNATIONAL (International channels)
CANADA (Canadian radio-telephone channels)
USA (Marine U.S. channels)
|
| Transducer | 8 elements of coupling and 1 sensor
|
| Outward porting (Input) | NMEA 0183 version 2 (data about true course from GPS)
|
| Outward porting (Output) | NMEA 0183 version 2 (data about bearing)
|
| Display | 5,5 inches, TFT color LCD, 320 õ 240 pix
|
| Screen background colors | black, cyan, blue (selectable)
|
| Information display colors | color, black-white (selectable)
|
| Voltage | 20 - 28 V DC
|
| Leakage current | not less than 6 À
|
| Working temperature | from -10 to +55°Ñ |
