| Parameters, function | Values
|
| Frequency range | Transmitting: 1.6 - 27.5 MHz
Receiving: 0.1 - 30 MHz
|
| Channels | 256 channels, programmed by service specialist, any of the following frequencies:
- All frequencies from MSA regulations (ITU RR Appendix 16) in a range 4 - 27.5 MHz
- All frequencies of alert for telephoning, DSC
- All telephone frequencies instructed by national administration in accordance with MSA regulations (ITU RR Article 8) in a range 1.6 - 4 MHz
|
| Applied rules and regulations | ITU-R Rec. 493-10 (Class A), 541-8, 1082-1
IEC 61097-3/61097-8/61097-9, IEC 61162-1, IEC 60945
IMO Res. A.804(19) and MSC.68(68), EN 300 338 stability frequency ±10 Hz (for telephoning)
|
| Communication system | Simplex and semi-duplex
|
| Class of emission | J3E (Telephoning)
J2B (DSC)
|
| Output capacity of transceiver | Model FS-1570: 150 W
Model FS-2570: 250 W
According to FCC 80.215:150 W in a range from 2 to 4 MHz, 400 W on frequency 2182 kHz, attenuator up to 60 W PEP.
Alert signal transmitting on a full power supply
|
| Antenna | Pin 7-18 m and beam antenna
|
| Speed of adjustment | 0,2 -2 seconds in average
|
| Receiver output | Is available to supply at least 2 W (1 W/8 Îm, 4 W/4 Îm)
|
| Digital Selective Call (DSC) | Call transmitting and alert message
|
| Message format | RR 3112: format indicator (alert), Marine Vessel Identificator, type of alert, alert positions, time, team DU (EOS, ECC)
|
| Frequency of alert and safety | 2187.5, 4207.5, 6312, 8414.5, 12577, 16804.5 kHz
|
| Frequencies of commercial DSC | 1.6 - 27.5 MHz (in model FS-2570 for commercial DSC an additional receiver is required)
|
| Frequency stability | ± 0.5 Hz
|
| Buffer of storage received messages | Up to 50 messages about alert plus 50 other messages
|
| Buffer of storage transmitting messages | 50 cells containing messages, phone numbers, working frequencies etc.
|
| Alarm | Sound and light alarm when:
- Receiving a message about alert, urgency or usual calls.
- Absence of positions from outward source of signal NMEA
|
| Display | 160 digits on 8 lines, 95 x 60 mm
|
| Frequency shift (DSC) | Pressing: 1615 Hz, gap 1785 Hz, 100 baud
|
| Interface of data transmitting | IEC 61162-1
|
| Power supply voltage | 24 V (DC)
|
| Consumed current (when transmitting) | 20 Ampere (150 W for model FS-1570)
35 Ampere (250 W for model FS-2570)
|
| Consumed current (when receiving) | 0.8 Ampere (150 W for model FS-1570 )
1.5 Ampere (250 W for model FS-2570) |
