| Parameters, function | Values
|
| Inverter input: |
|
| Input voltage range | 9,5 - 16,1 (models 12/1300/70 and 12/2000/120)
19,0 - 32,2 (models 24/1300/70 and 24/2500/70)
|
| Maximum input current | 200 A (model 12/1300/70)
400 A (model 12/2000/120)
150 A (model 24/1300/70)
300 A (model 24/2500/70)
|
| Consumption capacity without load | 6 W (models 12/1300/70, 12/2000/120 and 24/2500/70)
8 W (model 24/1300/70)
|
| Inverter output: |
|
| Output voltage | 230 V AC ±1%
|
| Frequency | 50/60Hz ±0,01% (crystal-controlled)
|
| Nominal capacity | 1300 W (model 12/1300/70)
2000 W (model 12/2000/120)
1300 W (model 24/1300/70)
2500 W (model 24/2500/70)
|
| Degree of efficiency during Ð nom. | 84% (model 12/1300/70)
85% (model 12/2000/120)
86% (model 24/1300/70)
87% (model 24/2500/70)
|
| Protection | from overcharge, from short circuit
|
| Battery charger input: |
|
| Input voltage | 200-250 V AC
|
| Maximum input current | 4,5 A (during 15 Â / 70 À) model 12/1300/70
7,7 A (during 15 Â / 120 À) model 12/2000/120
5,1 A (during 30 Â / 40 À) model 24/1300/70
8,7 A (during 30 Â / 70 À) model 24/2500/70
|
| Degree of efficiency | 81% (during 15 Â / 70 À) model 12/1300/70
81% (during 15 Â / 120 À) model 12/2000/120
81% (during 30 Â / 40 À) model 24/1300/70
81% (during 30 Â / 70 À) model 24/2500/70
|
| Ños / power factor | 1,0
|
| Battery charger output: |
|
| Current/voltage stability | ±1%
|
| Output current range | 0 - 70 A, Uíîì = 12 Â (model 12/1300/70)
0 - 120 A, Uíîì = 12 Â (model 12/2000/120)
0 - 40 A Uíîì = 24 Â (model 24/1300/70)
0 - 70 A, Uíîì = 24 Â (model 24/2500/70)
|
| Maximum voltage of pulses | Maximum 1,25
|
| Switching: |
|
| Maximum switching capacity | 3600 W
|
| A time of switching to a net voltage to inverter | 20 mc
|
| Switching capacity - inverter to a net | 187 V AC
|
